Description
Eurovisin EV-F0820GBL-A 8 Port PoE & 2 Up-Link Giga Port Network Switch (Malaysia)
| Network Standard | IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at |
| Port | 8*10/100Mbps RJ45 port
2*10/100/1000Mbps RJ45 uplink port |
| POE Power | 8*10/100Mbps RJ45 port support POE+
The whole power is 120W Each port max. power supply reached 30W |
| POE Connection | 1-8 port support IEEE802.3af/at
Both1/2+、3/6- and 4/5+、7/8- End-span 250M Transmission（Manually Open） |
| Performance | Store and forward
MAC address table 1k Switching capacity12Gbps |
| Forwarding Rate | 10BASE-T:14880PPS/port
100BASE-tx：14800pps/port 1000BASE-tx：148000pps/port |
| Port Function | Power priority mechanism, fast and forward, MAC automatic
learning and aging IEEE802.3X Full-duplex and backpressure for half-duplex mode |
| Environment | Operating Temperature：-10℃ – -55℃ |
| Power | Built in power base board
Input：220V，50HZ，Output：DC52V±5% 2.3A ≤120W |
| Weight &Size | 1KG
200mm×118mm×44mm(L×W×H) |
Product Overview:
The Eurovisin EV-F0820GBL-A is a high-performance 10-port PoE switch featuring 8×10/100 PoE ports and 2× Gigabit uplink ports. It is engineered for faster data transmission and reliable power supply over Ethernet. Designed to support surveillance systems and network expansion, this switch ensures seamless, stable performance in demanding environments.
Benefits:
– Fast Gigabit connectivity
– Simultaneous data & power over one cable
– Supports long-distance PoE devices
– Energy-efficient and silent
– Perfect for HD CCTV setups and data-heavy environments
Applications:
– IP CCTV camera systems
– Office LAN infrastructure
– IP telephony networks
– Wi-Fi access points
– Retail & industrial automation
FAQs:
Q: Does it support full Gigabit on all ports?
A: Yes, all 10 ports support 1Gbps speed.
Q: Can it power IP cameras and APs simultaneously?
A: Yes, up to 120W total PoE power across 8 ports.
Q: Is it suitable for 4K camera setups?
A: Absolutely, its Gigabit speed ensures smooth video transmission.
Why Choose Eurovisin EV-F0820GBL-A ?
8×10/100 PoE ports With 2× Gigabit ports and strong PoE output, this model ensures top-tier speed and efficiency for professional-grade surveillance and networking projects. It’s ideal for modern infrastructure in Bangladesh.
About Eurovisin EV-F0820GBL-A :
Eurovisin, a reputable Malaysian brand, is known for reliable networking and surveillance products. The EV-F0820GBL-A embodies durability, performance, and affordability in a single unit.
Eurovisin EV-F0820GBL-A price in Bangladesh, 8 port Gigabit PoE switch Bangladesh, Eurovisin network switch, PoE switch for IP camera, Eurovisin PoE gigabit switch, Eurovisin EV-F0820GBL-A specs, 8 port PoE switch with uplink, CCTV PoE switch Bangladesh, Malaysian PoE switch brand, Eurovisin PoE switch review.
